How do you clean an ODS sensor?

VIDEO

.

Hereof, how does an ODS sensor work?

The Oxygen Detection Safety-Pilot, or Oxygen Depletion Sensor (ODS), ensures that air levels are safe in your home. This device works by detecting the level of oxygen in the room of your vent-free unit. When functioning normally, the gas pilot in your unit burns, when exposed to air, with 22-22.5% oxygen.

Also Know, how do you clean a propane fireplace insert? How to Clean a Pilot Assembly on a Propane Fireplace

1. Turn off the fireplace if it is on and shut off the main gas valve.
2. Use a flashlight to look into the tube where the pilot flame comes out.
3. Use a can of compressed air to blow the dust and dirt off of the end of the innermost tube.
4. Turn the gas valve back on and attempt to light the pilot.

Moreover, how do you clean a ventless fireplace?

How to Clean Gas Fireplace Ventless Logs Putting Out Soot

1. Turn off the gas and electric leading to the fireplace.
2. Carefully remove the logs, stones and burner, and place them on a newspaper.
3. Attach a hose to the vaccum, and clean the inside of the firebox.
4. If doors are attached to your fireplace, clean them inside and out with a non-ammonia cleaner.

Can you vent a ventless fireplace?

Answer: Unfortunately, there is no way to convert a ventless fireplace into a vented fireplace. Ventless fireplaces are not designed to have a vent added to them. Your only alternative is to tear out the existing ventless fireplace and replace it with a vented fireplace.

Related Question Answers

How do you clean a pilot light?

Process

1. Turn off the gas leading to your furnace.
2. Open up furnace cover and look at the pilot light and thermocouple.
3. Set both pieces on the towel (or some other soft surface which you can clean easily later.
4. Use the wire brush to scrub the pilot light and thermocouple.

How do you clean ceramic logs?

Part 2 Cleaning the Logs

1. Scrub the logs. Once the logs are moved out of the fireplace, use a brush to remove the soot.
2. Wipe the logs with a rag. To remove soot still clinging to the logs, use a dry, soft rag.
3. Clean the logs with a damp rag.
4. Vacuum up the soot.

Why do ventless gas logs smell?

In fact, a faint gas smell is an unavoidable consequence of using gas fireplace logs. In a gas ventless fireplace, oxygen is provided by the air in your home. If that air contains impurities, those impurities are drawn in with the oxygen and can produce odors which are amplified by the flame.

Do ventless fireplaces cause soot?

The heat and moisture caused by the gas logs WILL dislodge creosote and wood soot present. The wood residues can drop on the logs or burner as well as being carried by the home's air currents, then recycled through the ventless log burner so these impurities are now heated and burned again.

How do you clean a vent free gas heater?

How to Clean a Ventless Gas Heater

1. Shut off the ventless gas heater's power and allow it to cool for 30 minutes or more.
2. Open the heater's access panel.
3. Vacuum out the inside of the panel to remove dust and dirt.
4. Spray compressed air into the hole in the pilot assembly near the burner to remove any dust that might block it.
5. Dampen a cloth.

Does gas fireplace need cleaning?

Gas fireplace chimneys should be inspected and cleaned annually. There will not be any soot or creosote in the chimney since you are not burning wood, but you may find bird nests that need to be removed.

Why does my vent free fireplace shut off?

The main reason ventless gas heaters are not dangerous is because they are all required by law to have an ODS pilot light that automatically shuts the whole unit off if it detects a low oxygen level, which is usually caused by the presence of carbon monoxide.

Why does my gas fireplace keep cutting off?

If you get dust in the pilot assembly and the pilot needs to be cleaned out, it produces a "lazy" flame, which will be disturbed by the draught of the main burners. The flame lifts away from the thermocouple and causes the temperature on the tip of the thermocouple to drop. This, in turn, makes the gas valve shut off.

Why is there black soot on my gas fireplace logs?

The most common causes of soot buildup in a gas fireplace are ceramic fire-logs that have been moved out of proper position and burner ports that are clogged. The other main cause of soot is clogged ports on the gas burner, which causes an incomplete or unbalanced burn and formation of soot on the logs and doors.

Why does my propane fireplace smell?

Propane itself doesn't have an odor. What you smell is an additive that helps identify leaks. If your fireplace is working properly, the smell would indicate your tank is running low because the concentration of the odor additive being sent into the burner is higher.

What does a thermocouple look like?

The thermocouple looks like a piece of metal tubing smaller than a soda straw. To find it, first locate the gas control box. This is the box that the main gas line enters, where you turn the gas on in the furnace. The other end of the thermocouple sits in the flame of the pilot light.

Do propane fireplaces need to be cleaned?

Propane burns very cleanly and leaves few messy waste products behind, resulting in fireplaces that use it requiring much less cleaning. However, propane fireplaces still require cleaning from time to time. In particular, it is important to keep the pilot assembly on a propane fireplace clear and clean.
